HB-2-30

Tocris Bioscience | Catalog # 8831

Fluorescent TG2/LRP1 substrate for imaging endocytosis
Tocris Bioscience

Key Product Details

Description

Fluorescent TG2/LRP1 substrate for imaging endocytosis

Wavelength

Excitation = 649 nm, Emission = 665 nm
View all Fluorescent Lysosome Probes »

Product Description

Key information:

HB-2-30 is a far-red fluorescent transglutaminase-2 (TG2) probe for imaging endocytosis in vitro and in vivo. HB-2-30 undergoes highly efficient endocytosis in complex with TG2 and α2-macroglobulin via the LRP1 pathway.

Used for: Imaging endocytosis in vitro and in vivo, explore targeted lysosomal degradation of secreted and cell surface proteins.

Application: Confocal microscopy.

Properties and Photophysical Data: Suitable for multiplexing and can be combined with DAPI (Cat. No. 5748) counter-staining. Excitation and emission maxima (λ) are 649 and 665 nm, respectively.

Scientific Data Images for HB-2-30

Application of HB-2-30 in vitro

Application of HB-2-30 in vitro.

Confocal microscopy images of bone marrow-derived dendritic cells from WT C57BL/6 mice (left) and TG2KO mice (right) incubated with 3μM HB-2-30. Cells were incubated for 90 minutes with the probe before being fixed, stained for nuclei (blue), and imaged. HB-2-30 signals is in red. Image kindly provided by Fu-Chen Yang and Harrison Besser, University or Stanford.
Application of HB-2-30 in vivo.

Application of HB-2-30 in vivo.

Ileum tissue sections from mice dosed with 10 mg/kg HB-2-30. WT C57BL/6 mice (left) and TG2KO mice (right) were dosed with HB-2-30 and sacrificed after 2 hours. Intestines were Swiss rolled, thin sectioned, stained for nuclei (blue), and imaged via confocal fluorescence microscopy. HB-2-30 signal is in red. Image kindly provided by Fu-Chen Yang and Harrison Besser, University or Stanford.

Licensing Information

Sold under license from Stanford University

Optical Data

HB-2-30 Dye Spectra
λabs 649 nm
λem 665 nm
Application Confocal microscopy

Spectra Viewer

Plan Your Experiments

Use our spectra viewer to interactively plan your experiments, assessing multiplexing options. View the excitation and emission spectra for our fluorescent dye range and other commonly used dyes.

Spectra Viewer
Spectra Viewer

Product Specifications for HB-2-30

Molecular Weight

1307.59

Formula

C66H86N10O14S2

Storage

Store at -20°C

Purity

≥90% (HPLC)

CAS Number

3031522-14-9

InChI Key

ILCHGSXJNAIGGG-AFAVFPMXSA-N

SMILES

O=C(N1[C@@H](CCC1)C(N[C@H](C(N)=O)CC2=CC=CC=C2)=O)[C@@H](NC([C@H](CC/C=C/C(N(C)C)=O)NC([C@H]3N(CCC3)C(C)=O)=O)=O)CCNC(CCCCC[N+]4=C(/C=C/C=C/C=C5C(C)(C6=CC(S(=O)(O)=O)=CC=C6N\5C)C)C(C)(C)C7=CC(S(=O)([O-])=O)=CC=C47)=O

The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.

Solubility

Solubility Soluble to 13.08mg/ml in DMSO

Calculators

Calculate the mass, volume, or concentration required for a solution.

=
x
x
g/mol

*When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and CoA (available online).

Calculate the dilution required to prepare a stock solution.

x
=
x

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Background References

References are publications that support the biological activity of the product.
