Human CL-P1/COLEC12 Antibody

Catalog #: AF2690
4 Citations 1 Review Datasheet / COA / SDS
Catalog # Availability Size / Price Qty
AF2690
AF2690-SP
Detection of CL‑P1/COLEC12 in HUVEC Human Cells by Flow Cytometry.
4 Images
Product Details
Citations (4)
FAQs
Supplemental Products
Reviews (1)
Summary Data Examples Preparation and Storage Reconstitution Calculator Background Product Datasheets Related Research Areas

Human CL-P1/COLEC12 Antibody Summary

Species Reactivity
Human
Specificity
Detects CL‑P1/COLEC12 in direct ELISAs and Western blots. In direct ELISAs, approximately 45% cross‑reactivity with recombinant mouse CL-P1 is observed.
Source
Polyclonal Goat IgG
Purification
Antigen Affinity-purified
Immunogen
Mouse myeloma cell line NS0-derived recombinant human CL‑P1/COLEC12 isoform 1
Leu57-Leu742
Accession # Q5KU26
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Applications

Recommended Concentration
Sample
Western Blot
0.1 µg/mL
Recombinant Human CL-P1/COLEC12 (Catalog # 2690-CL)
Flow Cytometry
2.5 µg/106 cells
See below
Blockade of Receptor-ligand Interaction
In a functional ELISA, 2-8 µg/mL of this antibody will block 50% of the binding of 250 ng/mL of biotinylated AGE‑BSA to immobilized Recombinant Human CL-P1/COLEC12 (Catalog # 2690-CL) coated at 5 µg/mL (100 µL/well). At 100 μg/mL, this antibody will block >90% of the binding.

CyTOF-ready
Ready to be labeled using established conjugation methods. No BSA or other carrier proteins that could interfere with conjugation.

Immunocytochemistry
5-15 µg/mL
Immersion fixed HUVEC human umbilical vein endothelial cells

Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.

Scientific Data

Flow Cytometry Detection of CL-P1/COLEC12 antibody in HUVEC Human Cells antibody by Flow Cytometry. View Larger

Detection of CL‑P1/COLEC12 in HUVEC Human Cells by Flow Cytometry. HUVEC human umbilical vein endothelial cells were stained with Goat Anti-Human CL-P1/COLEC12 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF2690, filled histogram) or isotype control antibody (Catalog # AB-108-C, open histogram), followed by Allophycocyanin-conjugated Anti-Goat IgG Secondary Antibody (Catalog # F0108).

Immunocytochemistry/ Immunofluorescence Detection of Human CL-P1/COLEC12 by Immunocytochemistry/Immunofluorescence View Larger

Detection of Human CL-P1/COLEC12 by Immunocytochemistry/Immunofluorescence MCAM and COLEC12 are novel BEC- and LEC- specific markers.Two new endothelial markers MCAM and COLEC12 (selected from our analysis of Dataset B) were used to stain (A) normal human lymph nodes together with two established vascular markers PV-1 (for BEC) and CLEVER-1 (for LEC). In addition, (B) chronically inflamed tonsils and (C) specimens from bladder cancer and colorectal cancer were stained with the antibodies against the indicated proteins. LYVE-1 and COLEC12 co-staining was done on colorectal cancer specimens, whereas the other stainings represent bladder cancer. MCAM staining colocalized very well with the established BEC marker PV-1 whereas no colocalization could be detected between MCAM and the established LEC markers LYVE-1 and podoplanin. COLEC12-staining on the other hand showed colocalization with LYVE-1 but not PV-1. White arrows point to areas of colocalization. Nuclear counterstaining was performed with DAPI. Scale bars represent 100 µm. Image collected and cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/24058540), licensed under a CC-BY license. Not internally tested by R&D Systems.

Immunocytochemistry/ Immunofluorescence Detection of Human CL-P1/COLEC12 by Immunocytochemistry/Immunofluorescence View Larger

Detection of Human CL-P1/COLEC12 by Immunocytochemistry/Immunofluorescence MCAM and COLEC12 are novel BEC- and LEC- specific markers.Two new endothelial markers MCAM and COLEC12 (selected from our analysis of Dataset B) were used to stain (A) normal human lymph nodes together with two established vascular markers PV-1 (for BEC) and CLEVER-1 (for LEC). In addition, (B) chronically inflamed tonsils and (C) specimens from bladder cancer and colorectal cancer were stained with the antibodies against the indicated proteins. LYVE-1 and COLEC12 co-staining was done on colorectal cancer specimens, whereas the other stainings represent bladder cancer. MCAM staining colocalized very well with the established BEC marker PV-1 whereas no colocalization could be detected between MCAM and the established LEC markers LYVE-1 and podoplanin. COLEC12-staining on the other hand showed colocalization with LYVE-1 but not PV-1. White arrows point to areas of colocalization. Nuclear counterstaining was performed with DAPI. Scale bars represent 100 µm. Image collected and cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/24058540), licensed under a CC-BY license. Not internally tested by R&D Systems.

Immunocytochemistry/ Immunofluorescence Detection of Human CL-P1/COLEC12 by Immunocytochemistry/Immunofluorescence View Larger

Detection of Human CL-P1/COLEC12 by Immunocytochemistry/Immunofluorescence MCAM and COLEC12 are novel BEC- and LEC- specific markers.Two new endothelial markers MCAM and COLEC12 (selected from our analysis of Dataset B) were used to stain (A) normal human lymph nodes together with two established vascular markers PV-1 (for BEC) and CLEVER-1 (for LEC). In addition, (B) chronically inflamed tonsils and (C) specimens from bladder cancer and colorectal cancer were stained with the antibodies against the indicated proteins. LYVE-1 and COLEC12 co-staining was done on colorectal cancer specimens, whereas the other stainings represent bladder cancer. MCAM staining colocalized very well with the established BEC marker PV-1 whereas no colocalization could be detected between MCAM and the established LEC markers LYVE-1 and podoplanin. COLEC12-staining on the other hand showed colocalization with LYVE-1 but not PV-1. White arrows point to areas of colocalization. Nuclear counterstaining was performed with DAPI. Scale bars represent 100 µm. Image collected and cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/24058540), licensed under a CC-BY license. Not internally tested by R&D Systems.

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Preparation and Storage

Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS.
Loading...
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: CL-P1/COLEC12

Collectins are a family of Ca++-dependent, C-type lectins that contain a collagenous domain and function as recognition molecules for molecular patterns found on pathogens (1‑4). Human collectin placenta 1 (CL-P1; also known as collectin sub-family member 12 and SRCL type I [scavenger receptor with C-type lectin type I]) is a 110 kDa member of the collectin family of glycoproteins (5, 6). CL-P1 is the only collectin known to be membrane bound, while CL-L1 (collectin liver-1) is the only known cytoplasmic collectin (1). Human CL-P1 is synthesized as a 742 amino acid (aa) type II transmembrane glycoprotein that contains an N-terminal 39 aa cytoplasmic domain, a 17 aa transmembrane segment, and a 686 aa C-terminal extracellular region (6). The short cytoplasmic domain contains an internalization motif (Y-K-R-F) while the extracellular region is complex, demonstrating a coiled-coil segment, a Ser-Thr rich region, a collagen-like structure and a C-type lectin/ carbohydrate recognition domain (CRD). Notably, this CRD recognizes galactose (and fucose) within the context of asialo‑orosomucoids associated with the Lewisx epitope (7, 8). CL-P1 has a 300 kDa trimeric form due to its collagen-like and coiled-coil helical domains (1, 5). There is a 97 kDa, alternate splice form of CL-P1 (SRCL type II) that shows a 120 aa truncation at the C-terminus. This effectively removes the entire CRD found on full‑length CL-P1 (6). Human CL-P1 is 93% aa identical to mouse CL-P1 over the entire extracellular region, and 87% aa identical over the CRD region (5, 9). Human CL-P1 is known to be expressed in vascular endothelial cells (5).

References
  1. van de Wetering, JK. et al. (2004) Eur. J. Biochem. 271:1229.
  2. Holmskov, U. et al. (2003) Annu. Rev. Immunol. 21:547.
  3. Hoppe, H-J. and K. Reid (1994) Protein Sci. 3:1143.
  4. Hickling, T.P. et al. (2004) J. Leukoc. Biol. 75:27.
  5. Ohtani, K. et al. (2001) J. Biol. Chem. 276:44222.
  6. Nakamura,K. et al. (2001) Biochem. Biophys. Res. Commun. 280:1028.
  7. Coombs, P.J. et al. (2005) J. Biol. Chem. 280:22993.
  8. Yoshida, T. et al. (2003) J. Biochem. 133:271.
  9. Nakamura, K. et al. (2001) Biochim. Biophys. Acta 1522:53.
Long Name
Collectin Placenta 1
Entrez Gene IDs
81035 (Human); 140792 (Mouse); 361289 (Rat)
Alternate Names
CL-P1; CLP1hCL-P1; COLEC12; collectin placenta 1; Collectin placenta protein 1; collectin sub-family member 12; collectin-12; NSR2; Nurse cell scavenger receptor 2; SCARA4; SCARA4NSR2; Scavenger receptor class A member 4; scavenger receptor class A, member 4; SRCL Type I; SRCLScavenger receptor with C-type lectin

Product Datasheets

You must select a language.

x
Product Datasheet
COA
SDS

Citations for Human CL-P1/COLEC12 Antibody

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

4 Citations: Showing 1 - 4
Filter your results:

Filter by:

  1. Rapid and Efficient Purification of Functional Collectin-12 and Its Opsonic Activity against Fungal Pathogens
    Authors: J Zhang, A Li, CQ Yang, P Garred, YJ Ma
    J Immunol Res, 2019-07-29;2019(0):9164202.
    Species: Human
    Sample Types: Cell Culture Supernates, Recombinant Protein
    Applications: ELISA Capture, Western Blot
  2. Scavenger receptor collectin placenta 1 is a novel receptor involved in the uptake of myelin by phagocytes
    Authors: JF Bogie, J Mailleux, E Wouters, W Jorissen, E Grajchen, J Vanmol, K Wouters, N Hellings, J Van Horsen, T Vanmierlo, JJ Hendriks
    Sci Rep, 2017-03-20;7(0):44794.
    Species: Human
    Sample Types: Cell Lysates, Whole Cells, Whole Tissue
    Applications: Flow Cytometry, IHC, Western Blot
  3. Soluble Collectin-12 (CL-12) Is a Pattern Recognition Molecule Initiating Complement Activation via the Alternative Pathway.
    Authors: Ma Y, Hein E, Munthe-Fog L, Skjoedt M, Bayarri-Olmos R, Romani L, Garred P
    J Immunol, 2015-08-19;195(7):3365-73.
    Applications: Flow Cytometry
  4. Plasticity of blood- and lymphatic endothelial cells and marker identification.
    Authors: Keuschnigg, Johannes, Karinen, Sirkku, Auvinen, Kaisa, Irjala, Heikki, Mpindi, John-Pat, Kallioniemi, Olli, Hautaniemi, Sampsa, Jalkanen, Sirpa, Salmi, Marko
    PLoS ONE, 2013-09-10;8(9):e74293.
    Species: Human
    Sample Types: Whole Tissue
    Applications: IHC-Fr
