Mouse CD3 Alexa Fluor® 488-conjugated Antibody

Name: Mouse CD3 Alexa Fluor® 488-conjugated Antibody
Brand: R&D Systems
SKU: FAB4841G
Rating: 5 (1 reviews)

Catalog #: FAB4841G
1 Citation 1 Review Datasheet / COA / SDS

Catalog #	Availability	Size / Price	Qty
FAB4841G-100
FAB4841G-025

Detection of CD3 in Mouse Splenocytes by Flow Cytometry.

2 Images

All CD3 Antibodies

Product Details

Citations (1)

FAQs

Supplemental Products

Reviews (1)

Summary Data Examples Preparation and Storage Reconstitution Calculator Background Product Datasheets Related Research Areas

Mouse CD3 Alexa Fluor® 488-conjugated Antibody Summary

Species Reactivity

Mouse

Specificity

Reacts with mouse TCR-associated CD3 complex that occurs on thymocytes and mature T cells.

Source

Monoclonal Rat IgG_2B Clone # 17A2

Purification

Protein A or G purified from hybridoma culture supernatant

Immunogen

T cell hybridoma D1

Formulation

Supplied in a saline solution containing BSA and Sodium Azide.

Label

Alexa Fluor 488 (Excitation= 488 nm, Emission= 515-545 nm)

Applications

Recommended Concentration

Sample

Flow Cytometry

5 µL/10⁶ cells

See below

Immunocytochemistry

8-25 µg/mL

See below

Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.

Scientific Data

Flow Cytometry

View Larger

Detection of CD3 in Mouse Splenocytes by Flow Cytometry. Mouse splenocytes were stained with Rat Anti-Mouse B220/CD45R APC‑conjugated Monoclonal Antibody (Catalog # FAB1217A) and either (A) Rat Anti-Mouse CD3 Alexa Fluor® 488‑conjugated Monoclonal Antibody (Catalog # FAB4841G) or (B) Rat IgG_2BAlexa Fluor 488 Isotype Control (Catalog # IC013G). View our protocol for Staining Membrane-associated Proteins.

Immunocytochemistry

View Larger

CD3 in Mouse Splenocytes. CD3 was detected and stained in immersion fixed adult mouse splenocytes using Rat Anti-Mouse CD3 Alexa Fluor® 488‑conjugated Monoclonal Antibody (green; Catalog # FAB4841G) at 5 µg/mL for 3 hours at room temperature. Cells were counterstained with DAPI (blue). Specific staining was localized to cell surfaces. View our protocol for Fluorescent ICC Staining of Non-adherent Cells.

Reconstitution Calculator

Preparation and Storage

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Protect from light. Do not freeze.

12 months from date of receipt, 2 to 8 °C as supplied.

Background: CD3

Monoclonal 17A2 was generated by immunizing rats with a T-cell hybridoma (1). This antibody has been shown to react with the epsilon chain of the CD3 complex (1). The CD3 protein complex is expressed on thymocytes and mature T-cells and, therefore, is a useful reagent to monitor T-cell frequencies in tissues.

References

Miescher, G.C. et al. (1989) Immunol. Lett. 23:113.

Entrez Gene IDs

916 (Human); 12501 (Mouse)

Alternate Names

CD_antigen: CD3e; CD3 antigen, delta subunit; CD3; CD3d antigen; CD3d antigen, delta polypeptide (TiT3 complex); CD3d molecule, delta (CD3-TCR complex); CD3-DELTA; CD3e antigen; CD3e antigen, epsilon polypeptide (TiT3 complex); CD3e molecule, epsilon (CD3-TCR complex); CD3e; CD3-epsilon; CD3g antigen; CD3g antigen, gamma polypeptide (TiT3 complex); CD3g molecule, epsilon (CD3-TCR complex); CD3g molecule, gamma (CD3-TCR complex); CD3G; CD3-GAMMA; FLJ17620; FLJ17664; FLJ18683; FLJ79544; FLJ94613; IMD18; MGC138597; T3DOKT3, delta chain; T3E; T-cell antigen receptor complex, epsilon subunit of T3; T-cell receptor T3 delta chain; T-cell surface antigen T3/Leu-4 epsilon chain; T-cell surface glycoprotein CD3 delta chain; T-cell surface glycoprotein CD3 epsilon chain; TCRE

Product Datasheets

Product Datasheet

COA

SDS

Product Specific Notices

This product is provided under an agreement between Life Technologies Corporation and R&D Systems, Inc, and the manufacture, use, sale or import of this product is subject to one or more US patents and corresponding non-US equivalents, owned by Life Technologies Corporation and its affiliates. The purchase of this product conveys to the buyer the non-transferable right to use the purchased amount of the product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). The sale of this product is expressly conditioned on the buyer not using the product or its components (1) in manufacturing; (2) to provide a service, information, or data to an unaffiliated third party for payment; (3) for therapeutic, diagnostic or prophylactic purposes; (4) to resell, sell, or otherwise transfer this product or its components to any third party, or for any other commercial purpose. Life Technologies Corporation will not assert a claim against the buyer of the infringement of the above patents based on the manufacture, use or sale of a commercial product developed in research by the buyer in which this product or its components was employed, provided that neither this product nor any of its components was used in the manufacture of such product. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, Cell Analysis Business Unit, Business Development, 29851 Willow Creek Road, Eugene, OR 97402, Tel: (541) 465-8300. Fax: (541) 335-0354.

Related Research Areas

Citation for Mouse CD3 Alexa Fluor® 488-conjugated Antibody

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

1 Citation: Showing 1 - 1
