Mouse CD3 Biotinylated Antibody

Name: Mouse CD3 Biotinylated Antibody
Brand: R&D Systems
SKU: BAM4841
Rating: 5 (1 reviews)

Catalog #: BAM4841 1 Review Datasheet / COA / SDS

Catalog #	Availability	Size / Price	Qty
BAM4841

Detection of CD3 in Mouse Splenocytes by Flow Cytometry.

2 Images

All CD3 Antibodies

Product Details

FAQs

Supplemental Products

Reviews (1)

Summary Data Examples Preparation and Storage Reconstitution Calculator Background Product Datasheets Related Research Areas

Mouse CD3 Biotinylated Antibody Summary

Species Reactivity

Mouse

Specificity

Detects mouse CD3. Recognizes mouse T cell receptor-associated CD3 complex that is expressed on thymocytes and mature T cells.

Source

Monoclonal Rat IgG_2B Clone # 17A2

Purification

Protein A or G purified from hybridoma culture supernatant

Immunogen

T cell hybridoma D1

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with BSA as a carrier protein.

Label

Biotin

Applications

Recommended Concentration

Sample

Flow Cytometry

0.25 µg/10⁶ cells

See below

Immunohistochemistry

Miescher, G.C. et al. (1989) Immunol. Lett. 23:113.

Immunoprecipitation

Miescher, G.C. et al. (1989) Immunol. Lett. 23:113.

Immunocytochemistry

8-25 µg/mL

See below

Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.

Scientific Data

Flow Cytometry

View Larger

Detection of CD3 in Mouse Splenocytes by Flow Cytometry. Mouse splenocytes were stained with (A) Rat Anti-Mouse Biotinylated CD3 Monoclonal Antibody (Catalog # BAM4841) or (B) Rat IgG2B Biotinylated isotype control antibody (Catalog # IC013B) followed by Streptavidin-Phycoerythrin (Catalog # F0040) and Rat Anti-Mouse B220/CD45R APC-conjugated Monoclonal Antibody (Catalog # FAB1217A). View our protocol for Staining Membrane-associated Proteins.

Immunocytochemistry

View Larger

CD3 in Mouse Splenocytes. CD3 was detected in immersion fixed mouse splenocytes using Rat Anti-Mouse CD3 Biotinylated Monoclonal Antibody (Catalog # BAM4841) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Streptavidin (yellow; Catalog # NL999) and counterstained with DAPI (blue). View our protocol for Fluorescent ICC Staining of Non-adherent Cells.

Reconstitution Calculator

Preparation and Storage

Reconstitution

Reconstitute at 0.5 mg/mL in sterile PBS.

Shipping

The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.

12 months from date of receipt, -20 to -70 °C as supplied.
1 month, 2 to 8 °C under sterile conditions after reconstitution.
6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: CD3

The T cell receptor (TCR)/CD3 complex consists of two variable antigen-recognition receptor chains (TCR-alpha/TCR-beta or TCR-gamma/TCR-delta) that are non-covalently linked to at least four different invariant chains: CD3 gamma, CD3 delta, CD3 epsilon, and the CD3 zeta chain that exists as either a homodimer or as a heterodimer with its splice-variant the CD3 eta chain. The CD3 complex functions to transduce intracellular signals during TCR antigen recognition. CD3 is expressed early in thymocyte development, and on a subset of NK cells. CD3 epsilon is one of at least three invariant proteins that associate with the variable antigen recognition chains of the T cell receptor and function in signal transduction.

References

Miescher, G.C. et al. (1989) Immunol. Lett. 23:113.

Entrez Gene IDs

916 (Human); 12501 (Mouse)

Alternate Names

CD_antigen: CD3e; CD3 antigen, delta subunit; CD3; CD3d antigen; CD3d antigen, delta polypeptide (TiT3 complex); CD3d molecule, delta (CD3-TCR complex); CD3-DELTA; CD3e antigen; CD3e antigen, epsilon polypeptide (TiT3 complex); CD3e molecule, epsilon (CD3-TCR complex); CD3e; CD3-epsilon; CD3g antigen; CD3g antigen, gamma polypeptide (TiT3 complex); CD3g molecule, epsilon (CD3-TCR complex); CD3g molecule, gamma (CD3-TCR complex); CD3G; CD3-GAMMA; FLJ17620; FLJ17664; FLJ18683; FLJ79544; FLJ94613; IMD18; MGC138597; T3DOKT3, delta chain; T3E; T-cell antigen receptor complex, epsilon subunit of T3; T-cell receptor T3 delta chain; T-cell surface antigen T3/Leu-4 epsilon chain; T-cell surface glycoprotein CD3 delta chain; T-cell surface glycoprotein CD3 epsilon chain; TCRE
