Simple Plex Human Carbonic Anhydrase IX/CA9 Cartridge

Catalog #: SPCKB-PS-001194 Datasheet / COA / SDS

Simple Plex Human Carbonic Anhydrase IX/CA9 assay kit for use on Ella instrument. Contains cartridge, sample diluent SD13, and wash buffer

Catalog #	Availability	Size / Price	Qty
SPCKB-PS-001194
SPCKA-PS-001194
SPCKC-PS-001194

Control Products Available

898074: Simple Plex Control for Human Carbonic Anhydrase IX/CA9

3 Images

All Carbonic Anhydrase IX/CA9 Simple Plex Assays

Product Details

Supplemental Products

Reviews

Summary Precision Recovery Linearity Data Examples Product Datasheets Preparation and Storage Background Related Research Areas

Simple Plex Human Carbonic Anhydrase IX/CA9 Cartridge Summary

Assay Type

Automated sandwich ELISA

Format

Microfluidic cartridge containing three Glass Nano Reactors (GNR)

Assay Length

90 minutes

Sample Type & Volume Required Per Well*

Cell Culture Supernates (25 uL), Serum (25 uL), EDTA Plasma (25 uL), Heparin Plasma (25 uL)

Sensitivity

1.28 pg/mL

Assay Range

4.5 - 17,060 pg/mL (Cell Culture Supernates, Serum, EDTA Plasma, Heparin Plasma)

Specificity

Natural and recombinant human CA9.

Cross-reactivity

< 0.5% cross-reactivity observed with available related molecules.< 50% cross-species reactivity observed with species tested.

Interference

No significant interference observed with available related molecules.

*The Sample Volume represented is based on the amount of sample incorporated into the reaction after taking into account the assay’s minimum required dilution for a given matrix. Serial dilution may be necessary to achieve some of the final sample volumes represented.

Product Summary

Simple Plex assay for the detection of human CA9 in cell culture supernatant (CCS), serum, and plasma (EDTA/Heparin)

Precision

Intra-Assay Precision (Precision within an assay) Each control was tested 16 times in one assay

Inter-Assay Precision (Precision between assays) Replicates of each control were tested in multiple assays performed by at least three technicians using two lots of reagents

Cell Culture Supernates, Serum, EDTA Plasma, Heparin Plasma

	Intra-Assay Precision		Inter-Assay Precision
Sample	1	2	1	2
n	16	16	33	32
Mean (pg/mL)	100	4692	104	4671
Standard Deviation	4.36	357	7.92	417
CV%	4.4	7.6	7.6	8.9

Recovery

Recovery at three different spiked concentrations within the range of the assay was evaluated.

Sample Type	Average % Recovery	Range %
EDTA Plasma (n=4)	103	94-118
Heparin Plasma (n=4)	100	93-105
Serum (n=4)	110	106-117

Linearity

Samples containing and/or spiked with high concentrations of human CA9 were serially diluted with Sample Diluent to produce samples within the dynamic range of the assay

Scientific Data

N/A

View Larger

Human CA9 Simple Plex Assay Standard Curve

Product Datasheets

Product Datasheet

COA

SDS

Preparation and Storage

Shipping

The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.

Storage

Store the unopened product at 2 - 8 °C. Do not use past expiration date.

Background: Carbonic Anhydrase IX/CA9

Carbonic anhydrases catalyze the reversible reaction of CO2 + H2O = HCO3- + H+, which is fundamental to many processes such as respiration, renal tubular acidification and bone resorption. Human members of the CAs are secreted (CA6), membrane-bound (CA4, 9 to 12 and 14), cytosolic (CA1 to 3, 7, 8 and 13) or mitochondrial (CA5A and 5B). Some CAs may serve as markers for tumors and hypoxia. A subset of CAs lack CA activity due to point mutations but retain esterase function.

Entrez Gene IDs:

768 (Human); 230099 (Mouse)

Alternate Names:

CA9; CAIX; CA-IX; Carbonate dehydratase IX; carbonic anhydrase 9; Carbonic Anhydrase IX; carbonic dehydratase; EC 4.2.1.1; G250; Membrane antigen MN; MN; P54/58N; PMW1; RCC; RCC-associated antigen G250; RCC-associated protein G250; Renal cell carcinoma-associated antigen G250
