Simple Plex Human MIF Cartridge

Catalog #: SPCKB-PS-000512 Datasheet / COA / SDS

Simple Plex Human MIF assay kit for use on Ella instrument. Contains cartridge, sample diluent SD13, and wash buffer

Catalog #	Availability	Size / Price	Qty
SPCKB-PS-000512
SPCKA-PS-000512
SPCKC-PS-000512

Control Products Available

898149: Simple Plex Control for Human MIF

3 Images

All MIF Simple Plex Assays

Product Details

Supplemental Products

Reviews

Summary Precision Recovery Linearity Data Examples Product Datasheets Preparation and Storage Background Related Research Areas

Simple Plex Human MIF Cartridge Summary

Assay Type

Automated sandwich ELISA

Format

Microfluidic cartridge containing three Glass Nano Reactors (GNR)

Assay Length

90 minutes

Sample Type & Volume Required Per Well*

Cell Culture Supernates (10 uL), Serum (10 uL), Platelet-poor EDTA Plasma (10 uL), Platelet-poor Heparin Plasma (10 uL), Urine (10 uL), Cerebrospinal Fluid (25 uL)

Sensitivity

5.74 pg/mL

Assay Range

26.3 - 16,020 pg/mL (Cell Culture Supernates, Serum, Platelet-poor EDTA Plasma, Platelet-poor Heparin Plasma, Urine, Cerebrospinal Fluid)

Specificity

Natural and recombinant human MIF.

Cross-reactivity

< 0.5% cross-reactivity observed with available related molecules.< 50% cross-species reactivity observed with species tested.

Interference

No significant interference observed with available related molecules.

*The Sample Volume represented is based on the amount of sample incorporated into the reaction after taking into account the assay’s minimum required dilution for a given matrix. Serial dilution may be necessary to achieve some of the final sample volumes represented.

Product Summary

Simple Plex assay for the detection of human Macrophage Migration Inhibitory Factor (MIF) in cell culture supernatant (CCS), serum and platelet-poor plasma (EDTA/Heparin), urine, and cerebrospinal fluid (CSF).

Precision

Intra-Assay Precision (Precision within an assay) Each control was tested 16 times in one assay

Inter-Assay Precision (Precision between assays) Replicates of each control were tested in multiple assays performed by at least three technicians using two lots of reagents

Cell Culture Supernates, Serum, Platelet-poor EDTA Plasma, Platelet-poor Heparin Plasma, Urine, Cerebrospinal Fluid

	Intra-Assay Precision		Inter-Assay Precision
Sample	1	2	1	2
n	16	16	20	19
Mean (pg/mL)	108	5001	99.1	4400
Standard Deviation	4.76	263	6.02	375
CV%	4.4	5.3	6.1	8.5

Recovery

Recovery at three different spiked concentrations within the range of the assay was evaluated.

Sample Type	Average % Recovery	Range %
Cell Culture Media (n=2)	106	105-107

Linearity

Samples containing and/or spiked with high concentrations of human MIF were serially diluted with Sample Diluent to produce samples within the dynamic range of the assay

Scientific Data

N/A

Human MIF Simple Plex Assay Standard Curve

View Larger

Human MIF Ella Assay Standard Curve

Product Datasheets

Product Datasheet

COA

SDS

Preparation and Storage

Shipping

The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.

Storage

Store the unopened product at 2 - 8 °C. Do not use past expiration date.

Background: MIF

MIF (macrophage migration inhibitory factor) is a pro-inflammatory cytokine that is released during microbial infection, ARDS, rheumatoid arthritis, atherosclerosis, type 2 diabetes, and cancer. It signals through CXCR4, CXCR7, or complexes of CD74-CD44. MIF exhibits potent paracrine and autocrine stimulatory effects on cell growth and survival and enhances the production of inflammatory cytokines. It also inhibits the effectiveness of immunosuppressive glucocorticoids.

Long Name:

Macrophage Migration Inhibitory Factor

Entrez Gene IDs:

4282 (Human); 17319 (Mouse)

Alternate Names:

EC 5.3.2.1; EC 5.3.3.12; GIFmacrophage migration inhibitory factor; GLIF; Glycosylation-inhibiting factor; L-dopachrome isomerase; L-dopachrome tautomerase; macrophage migration inhibitory factor (glycosylation-inhibiting factor); MIF; MMIF; Phenylpyruvate tautomerase
